Evaluations

Evaluations let you define custom quality metrics for your LLM outputs and measure them against real production traces.

Zespan evaluations dashboard showing score trends and per-trace results

Instead of guessing whether a prompt change improved quality, you define what “good” means numerically, run an evaluation, and see scores trend over time. Zespan uses an LLM-as-judge approach: your evaluator definition is a prompt that an AI model applies to each trace, producing a numeric score.

Auto-evaluations with 12 built-in LLM-as-judge templates are available on Solo and above. Manual evaluation runs are available on all plans including Free.

How evaluations work

An evaluator (EvaluatorDefinition) is a named metric — at minimum a name, a metric key, and an optional description. When an evaluator runs (manually, on auto-run, or from a dataset-run score) against a trace, Zespan submits the trace’s prompt/completion text to an LLM judge, which returns a numeric score. Scores are stored and displayed as trends on the Evaluations page. There are two ways to get an evaluator with a real rubric:

New Evaluator dialog — the fast path. It only collects Name, Metric Key, and an optional Description; it does not let you write a scoring prompt. An evaluator created this way scores traces using Zespan’s generic default judge prompt (“evaluate output quality against input intent, score 0.0–1.0”) rather than a rubric you author.
Templates → Deploy — the path for a custom rubric, score range, and input scope. See Custom evaluator templates below.

You can also attach scores programmatically from the SDK using span.setEvalScore(), bypassing the judge model entirely. Both sources — programmatic and LLM-as-judge — appear in the same dashboard.

Creating an evaluator

Open the Evaluations page

Navigate to Evaluations in the left sidebar.

Click New Evaluator

The evaluator creation dialog opens.

Name it and set a metric key

Give it a name (e.g. Factuality Check) and a metric key (e.g. custom_relevance). The metric key becomes the identifier in trend charts. Optionally add a description.

Save

Click Save. The evaluator appears in your evaluator list, ready to run with the default judge prompt described above.

If you need a custom scoring prompt, a specific score range, categorical/boolean verdicts, or an input scope (prompt vs. completion vs. both), don’t use the New Evaluator dialog — create a custom template instead and deploy it. Deploying a template creates the same kind of evaluator, just with your rubric attached instead of the generic default.

Evaluations work on stored prompt and completion text. If you have disabled prompt storage with storePrompts: false, evaluation results will be empty — re-enable it to use evaluations.

Creating an evaluator via the New Evaluator dialog requires the Team plan or above. Deploying a template into an evaluator does not have this restriction — see Custom evaluator templates. Editing or deleting an evaluator — however it was created — also requires Team. See Plan limits.

Custom evaluator templates

Beyond the built-in library, you can author your own evaluator templates from the Templates tab on the Evaluations page. Built-in and custom templates live in the same catalog — you browse both, then deploy any of them into a live evaluator when you’re ready. This is where you write an actual scoring prompt/rubric — the New Evaluator dialog above does not expose one.

Open the Templates tab

Navigate to Evaluations and select the Templates tab.

Click Create Template

The Create Custom Template dialog opens.

Name it and pick a category

Give the template a name, and a category such as quality, safety, performance, agent, or rag — or type your own.

Write the judge's system prompt

This is the rubric the judge model applies to each trace — describe what to look for and how to score it, the same way you would for a built-in template.

Set a metric key and a pass/fail threshold

The metric key becomes the identifier for this evaluator in trend charts. The threshold (0.0–1.0) is the cutoff score above which a result counts as a pass.

Choose a score type

Select how the judge should express its verdict:

Numeric — a score between 0.0 and 1.0
Categorical — the judge picks exactly one label from a list you define, entered as comma-separated values, e.g. helpful, unhelpful, unclear
Boolean — a true/false verdict

Optionally pin a judge model

Override the project’s default judge model for this template alone. See Overriding the judge model per template below.

Test it, then save

Use Test on a real trace to preview scoring before saving — see Testing a template before you deploy it below. When you’re satisfied, click Create Template.

The new template appears in the catalog alongside the built-in ones. Click Deploy on its row to turn it into a live evaluator, the same way you would enable any built-in template.

Overriding the judge model per template

By default, every evaluator uses your project’s default judge model. When creating a custom template, you can pin a specific judge for that template instead: choose a provider — OpenAI, Anthropic, or Google — and enter the model name (for example gpt-4o, claude-sonnet-4-20250514, or gemini-2.5-flash). Leave the provider set to its default option to keep using the project’s default judge model. This lets you match judge cost and strength to the rubric — a cheaper, faster model for a simple pass/fail check, a stronger model for a template that requires nuanced judgment.

Testing a template before you deploy it

Before saving a new template, use the Preview & Test panel in the creation dialog to see how it scores. Click Test on a real trace to submit your rubric, along with your most recently ingested trace, to the judge model synchronously. The result — a score and the judge’s reasoning — appears in the dialog within a few seconds.

A dry run doesn’t create an evaluator or save any results. It’s a quick check that your rubric produces the score you expect before you commit to deploying it.

Every LLM-judge call — the template dry run above, auto-evaluation, a manual Run now, and the ad-hoc playground run described below — requires a project LLM connection. Without one, the call fails with “No LLM connection configured — add one in Settings → LLM Connections.” Connect a provider key under LLM Connections before using any of these.

Scope: trace vs. session

Every template above judges a single trace by default (scope: "trace"). Setting scope: "session" instead makes the deployed evaluator judge an entire conversation — every trace sharing a sessionId, folded into one ordered transcript — rather than one call in isolation. This is useful for quality signals that only show up across multiple turns, like the assistant contradicting itself or drifting off-topic over a long back-and-forth. The Create Custom Template dialog doesn’t expose a scope toggle yet, so set it via the API when creating or updating a template:

curl -X POST https://api.zespan.com/v1/projects/{projectId}/evaluation-templates \
  -H "Authorization: Bearer $ZESPAN_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{
    "name": "Conversation coherence",
    "category": "quality",
    "evaluatorType": "llm_judge",
    "metricKey": "conversation_coherence",
    "defaultThreshold": 0.7,
    "systemPrompt": "Judge whether the assistant stayed coherent across the whole conversation...",
    "scope": "session"
  }'

Deploy it from the Templates tab the same way as any other template — the scope carries over to the live evaluator automatically. A session-scope evaluator never scores an individual trace; it only runs once a session is detected as complete, and its results are written separately from per-trace scores (no traceId/spanId, a sessionId instead). See Session-level evaluation for how “session complete” is detected and where these scores are surfaced.

Running evaluations

After creating an evaluator, you run it against a selection of traces. Auto-evaluation: Enable Auto-run on an evaluator to have it score every new trace automatically as it arrives. This is useful for monitoring ongoing quality in production. Manual run: Click Run now on any evaluator to score a batch of recent traces immediately. You can choose how many recent traces to include (up to 500). Both modes display results in the evaluator’s trend chart within a few minutes of completion.

Scoring a Playground response

You can also run an evaluator outside this page entirely: on the Playground page, each output window has a Run Eval action that lets you pick any evaluator from this project and score that window’s prompt/response pair synchronously — useful for checking how an evaluator would score a draft response before it ever becomes a trace. Like every other judge call described above, it requires a project LLM connection.

Sampling and filters for auto-evaluation

When an evaluator is running continuously against live traffic, you can scope exactly which traces it judges instead of scoring every single one. Open the Evaluators tab and click the gear icon next to an active evaluator to open Sampling & Filters. You can configure:

Sample rate — a fraction from 0 to 1 of matching traces to judge. Set it to 0.1, for example, to evaluate roughly 1 in 10 matching traces and control judge-model cost; leave it at 1.0 to evaluate every eligible trace.
Minimum output tokens — skip traces whose output is shorter than this token count, so trivially short responses don’t consume judge calls.
Models — a comma-separated list of model names to restrict evaluation to, e.g. gpt-4o, claude-sonnet-4-20250514.
Operations — a comma-separated list of operation types to restrict evaluation to, e.g. chat, completion.
Statuses — a comma-separated list of trace statuses to restrict evaluation to, e.g. success.

Leave any filter blank to match everything. Use the Sampling Enabled toggle to turn sampling on or off without losing your configured values, then click Save to apply.

Combine sampling and filters to scope auto-evaluation to the slice of traffic you actually care about — for example, judge only 20% of chat operations on your production model, skipping short responses that wouldn’t produce a meaningful score.

Reading evaluation results

A categorical or boolean evaluator (see Custom evaluator templates) displays its result as the judge’s chosen label, or true/false, in the Evaluators table on the trace detail view. It no longer renders as a 0–100% bar there: a percentage has no meaning for a label like helpful or a boolean verdict. This is scoped to that one surface — the cards and tables on this page, and the generic score chip used elsewhere, still show a raw percentage regardless of score type. Numeric evaluators are unaffected everywhere and still show a 2-decimal score with the usual progress bar.

The main Evaluations page shows all your evaluators as cards. Each card displays:

Name — the evaluator identifier
Latest score — the most recent average score across the last batch of evaluated traces
Trend — a sparkline showing how the score has changed over the last 30 days
Sample count — how many traces were scored in the latest run

Click an evaluator card to open the full detail view with:

A time-series chart of average score by day
A distribution histogram showing score spread
A table of individual trace scores with links to the trace detail view

If your evaluator score drops sharply after a deployment, open the Traces page and filter to the same time window. The evaluation score is shown in the trace detail panel so you can correlate low-scoring traces with specific model calls.

Evaluating RAG pipelines

If your traces include retrieval spans — captured automatically by recordRetrieval(), the LangChain integration, or attached manually via span.recordDocuments() (span_kind: "retriever") — five evaluator templates can score the retrieval step itself, not just the final answer:

Template	What it checks	Requires retrieved chunks
Groundedness	Whether the response is supported by whatever context is available — retrieved chunks if present, the trace’s system prompt otherwise	No — degrades gracefully
RAG Faithfulness	Whether every claim in the response is specifically supported by the retrieved chunks	Yes
Context Relevance	Whether the retrieved chunks are actually relevant to the query — judges the retriever, independent of the generated answer	Yes
Context Utilization	What fraction of retrieved chunks were actually used in the response	Yes
Retrieval Hit Rate	Deterministic, no LLM call — did the retriever return anything at all	Yes

All five are reference-free, like every other evaluator on this page — no ground-truth answer set required. Deploy any of them from the Templates tab under the RAG category, the same way you’d deploy any built-in template.

The four RAG-specific templates — everything except Groundedness — only score traces that actually have a retrieval span with chunks. A trace with no retrieval step is skipped for these evaluators entirely: no score row, no LLM call, no cost, rather than a meaningless score against nothing.

RAG analytics

The Retrieval tab on this page rolls RAG evaluator scores up across traces: a trend card per metric, and a ranked list of your worst-performing retrieval operations — the fastest way to spot a retriever that’s degraded on one specific operation before it shows up as a wave of bad answers.

If Retrieval Hit Rate is trending down on an operation, check that first. A faithfulness or context-relevance drop is often downstream of the retriever returning nothing, not the judge model getting worse.

Attaching scores from the SDK

You can attach evaluation scores to any span programmatically using span.setEvalScore(). This is useful when you compute quality scores in your own code — for example, using a custom similarity function for RAG faithfulness.

TypeScript
Python

import { zespan, startSpan } from "@zespan/sdk";

const { span } = startSpan({ name: "rag-pipeline", provider: "custom" });

try {
  const answer = await generateAnswer(query, docs);

  // Attach your computed scores before closing the span
  span.setEvalScore("faithfulness", computeFaithfulness(answer, docs));
  span.setEvalScore("relevance", computeRelevance(answer, query));

  await span.end({ status: "success" });
  return answer;
} catch (err) {
  await span.end({ status: "error", error_message: String(err) });
  throw err;
}

from zespan import start_span

with start_span(name="rag-pipeline", provider="custom") as span:
    answer = generate_answer(query, docs)

    span.set_eval_score("faithfulness", compute_faithfulness(answer, docs))
    span.set_eval_score("relevance", compute_relevance(answer, query))

Scores attached via the SDK appear in the same trend charts as LLM-as-judge scores. If you attach a score with the same name as an evaluator, both sources are shown together in the detail view — and, as of this dashboard’s KPI tiles and metric list, in the aggregate too: setEvalScore() results and server-side judge results for the same metric key are combined into one count-weighted average per time bucket rather than only ever appearing in the raw per-trace view. No setup is required on your side; this happens automatically the moment a span carries an eval score.

Performance & agent evaluators

Four built-in templates score performance and agent-trajectory signals directly from trace data — no LLM call, no judge cost:

Template	Metric key	What it checks	Requires
Latency SLA	`latency_sla`	Whether the span’s `latency_ms` is within a target (default 5000ms)	The span’s latency to be recorded
Cost Budget	`cost_budget`	Whether the span’s `cost_usd` is within a budget (default $0.05)	The span’s cost to be recorded
Loop Detection	`loop_detection`	The longest run of consecutive identical operations across the trace’s spans so far — a sign of an agent stuck repeating the same tool call	At least 2 spans in the trace
Error Recovery Rate	`error_recovery_rate`	Of the trace’s error spans, what fraction were followed later by a successful call to the same operation — a retry-and-recover pattern	At least 1 error span in the trace

Each is a real deterministic check against the trace’s own data (latency_ms, cost_usd, operation, status) — not a generic LLM quality-judge rubric scoring “output quality” in the abstract. Loop Detection and Error Recovery Rate skip a trace entirely (no score row, no cost) when there isn’t enough signal yet — fewer than 2 spans, or no error spans respectively — rather than fabricate a score against nothing.

slaTargetMs (Latency SLA) and budgetUsd (Cost Budget) use fixed defaults (5000ms / $0.05) for every evaluator deployed from these templates. There’s no dashboard control to change these per-evaluator yet — reach out if you need a different threshold.

Retroactive evaluation

An evaluator only auto-scores traffic from the moment it’s turned on — but you don’t need to have predicted which metric you’d want in advance. The Retroactive Runs panel on this page scores historical traces you’ve already ingested against any evaluator, including one that wasn’t configured for auto-run (or didn’t exist yet) when that traffic actually happened.

Click Run retroactively

Opens the retroactive-run dialog. Requires at least one evaluator to already exist.

Pick an evaluator

Choose any existing evaluator — built-in or custom, numeric, categorical, or boolean.

Set a time range

Pick a From and To date/time — the historical window to score. “From” must be earlier than “To”.

Optionally narrow by operation or model

Enter an operation (e.g. chat.completions.create) or model name (e.g. gpt-4o-mini) to restrict scoring to a slice of that time range instead of everything in it.

Run

Zespan resolves every matching trace and scores it with the same LLM-judge pipeline a live auto-evaluation run uses.

Watching progress

Each run appears in the Retroactive Runs list with a progress bar and status label:

Status	Meaning
Queued	The run has been created and enqueued, not yet picked up.
Running — X/Y traces scored	The worker is actively scoring; X of Y matched traces are done so far.
Completed — X/Y traces scored	Every matched trace has been scored (or the run finished with zero matches).
Failed	The run couldn’t complete — for example, no LLM connection was configured for the judge model. The failure reason is shown inline when available.

The list refreshes automatically while any run is still Queued or Running, so you don’t need to reload the page to watch a run finish.

A retroactive run’s results land in the same score data as any other evaluator run, so they appear in that evaluator’s trend chart and everywhere else its scores are shown — no separate “retroactive results” view to check.

Need a human to review traces directly instead of running them through an LLM judge — for calibration, or for cases too ambiguous to trust to a judge model? See Annotation Queues.

Plan limits

Plan	Auto-evaluation	Built-in templates	Monthly scored traces
Free	Manual only	—	500
Solo	Included (12 templates)	12	5,000
Pro	Included	12 + custom	25,000
Team	Included	12 + custom	100,000
Scale	Included	12 + custom	Unlimited

This table covers auto-evaluation and template access, not evaluator management. Deploying a template into a live evaluator has no separate plan gate on any of the plans above (only the evaluations:manage permission). Using the New Evaluator dialog to create one directly, or editing/deleting any existing evaluator, requires the Team plan or above regardless of which plan row you’re on.
